Ultra Filtration Water Treatment Plant

10000.00 - 100000.00 INR/Piece

Get a Price/Quote

Product Details:

Water Out Conductivity 15 S/cm
Efficiency (%) 98%
Recycle Rate 95%
Noise Level < 75 dB
Pump Type Centrifugal / High-Pressure Pump
Flow Rate 500-50,000 LPH
Technology Hollow Fiber UF Membrane
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Ultra Filtration Water Treatment Plant Price And Quantity

Minimum Order Quantity 1 Piece
Price Range 10000.00 - 100000.00 INR/Piece

Operating Pressure 1-4 bar
Turbidity Removal < 0.1 NTU
Pipe Material UPVC/SS/MS
Backwash System Automatic/Manual
Control Panel PLC/Touch Screen
Cleaning Frequency Automatic/Manual as per Feed Water Quality
End Connection Flanged/Threaded
Inlet Pressure 0.1~0.3 MPa
Ambient Temperature 5°C-45°C
Pretreatment Required Yes (Sand Filter, Activated Carbon Filter, etc.)
Installation Service Available
Design Life of Membrane 3-5 Years
Membrane Material PVDF/PS/ PES

Ultra Filtration Water Treatment Plant Product Specifications

Noise Level < 75 dB
Recycle Rate 95%
Water Out Conductivity 15 S/cm
Efficiency (%) 98%
Flow Rate 500-50,000 LPH
Pump Type Centrifugal / High-Pressure Pump
Drive Type Electric Motor Driven
Technology Hollow Fiber UF Membrane
Power Consumption 1.5-10 kW (Depending on Model)
Usage & Applications Drinking Water, RO Pre-treatment, Industrial, Commercial
Purity Level Up to 99.99%
Installation Type Skid Mounted / Containerized / Customized
Automatic Grade Automatic
Filter Type Hollow Fiber/Cartridge
Capacity 500 LPH to 50,000 LPH
Voltage 380V / 220V / 50Hz
Product Type Ultra Filtration Water Treatment Plant
Feature Low Maintenance, High Productivity, Compact Design
Water in conductivity 800 S/cm
Material Stainless Steel (SS304/316), FRP
Ph Level 6.5-8.5
Power Source Electric
Volume As per Plant Capacity
Water Source Borewell, River, Municipal Supply, etc.
Frequency 50-60Hz

Operating Pressure 1-4 bar
Turbidity Removal < 0.1 NTU
Pipe Material UPVC/SS/MS
Backwash System Automatic/Manual
Control Panel PLC/Touch Screen
Cleaning Frequency Automatic/Manual as per Feed Water Quality
End Connection Flanged/Threaded
Inlet Pressure 0.1~0.3 MPa
Ambient Temperature 5°C-45°C
Pretreatment Required Yes (Sand Filter, Activated Carbon Filter, etc.)
Installation Service Available
Design Life of Membrane 3-5 Years
Membrane Material PVDF/PS/ PES

Ultra Filtration Water Treatment Plant Trade Information

Supply Ability 1 Piece Per Day
Delivery Time 1 Days

Product Description

Capitalizing on the skills and dedication of our talented professionals, we are providing a supreme range of Ultra Filtration Water Treatment Plant. It is a filtration plant which has a pressure membrane for the process of separation. Apart from this, provided plant is easy to operate and maintain. Ultra Filtration Water Treatment Plant has a sturdy construction to increase its quality. It eliminates viruses and harmful bacteria. It ensures low maintenance and gives a high performance system.

Advanced Filtration Technology

This plant leverages hollow fiber UF membranes made of PVDF, PS, or PES to deliver exceptional filtration efficiency (up to 98%). The system efficiently removes turbidity and contaminants, making it compatible with a wide variety of water sources. Operational versatility is enhanced by automatic or manual cleaning cycles, adapting seamlessly to the feed water quality.

User-Friendly Control and Low Maintenance

Equipped with a PLC or touch screen control panel, the Ultra Filtration System guarantees straightforward monitoring and adjustment. The automatic/manual backwash system simplifies maintenance procedures, while the robust construction using UPVC, SS, or MS pipes ensures longevity.

Scalable, Compact, and Versatile Design

The plant supports flow rates from 500 to 50,000 LPH and is available in skid-mounted, containerized, or customized formats. Its compact design makes it ideal for space-constrained installations. Installation services are available, ensuring precision setup for both industrial and commercial applications.

FAQ's of Ultra Filtration Water Treatment Plant:

Q: How does the Ultra Filtration Water Treatment Plant operate?

A: The plant uses hollow fiber UF membranes under a pressure range of 1-4 bar to filter water, removing suspended particles and reducing turbidity to less than 0.1 NTU. Automatic or manual backwash cycles maintain membrane performance, and a PLC or touch screen interface allows users to manage operations conveniently.

Q: What types of water sources are suitable for use with this plant?

A: This filtration system is compatible with borewell, river, and municipal water supplies. Before filtration, pretreatment with sand and activated carbon filters is required to optimize membrane lifespan and water quality.

Q: When should the membranes be cleaned or replaced?

A: Membranes should be cleaned automatically or manually, depending on the feed water quality and operating conditions. With proper maintenance, the design life of the membranes ranges from 3 to 5 years before replacement is necessary.

Q: Where can the Ultra Filtration Water Treatment Plant be installed?

A: Thanks to its compact and modular design, the plant can be installed in industrial, commercial, or institutional settings. Skid-mounted, containerized, or customized installation types are available, supported by expert installation services across India.

Q: What is the filtration process, and which pretreatment steps are required?

A: The multi-stage process starts with pretreatment using sand and activated carbon filters to remove large particles and chemicals, followed by fine filtration through hollow fiber membranes. This sequence ensures efficient removal of turbidity and ensures optimal membrane function.

Q: How can this system be used, and what are its main benefits?

A: The plant is used primarily for producing high-quality drinking water, serving as RO pre-treatment, and supporting industrial or commercial operations. Benefits include high productivity, low maintenance, compact design, energy efficiency, and superior water purity (up to 99.99%).

Q: What are the advantages of the automatic backwash and PLC control features?

A: Automatic backwash reduces manual maintenance and prolongs membrane life, while PLC or touch screen control offers intuitive system management, operational flexibility, and real-time status monitoring for reliable, efficient filtration performance.
