5000 LPH RO Plant

Name: 5000 LPH RO Plant
Brand: H2O ION EXCHANGE
Price: 350000 INR
Availability: InStock

350000 INR/Piece

Get a Price/Quote

Product Details:

Water in conductivity <2000 S/cm
Water Out Conductivity <10 S/cm
Noise Level <70 dB
Pump Type High Pressure Multistage Pump
Frequency 50 Hz
Flow Rate 5000 LPH
Feature Mild Steel
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

5000 LPH RO Plant Price And Quantity

Price 350000 INR/Piece
Minimum Order Quantity 1 Piece
Price Range 10000.00 - 100000.00 INR/Piece

Dimensions (LxWxH) Approx. 2600mm x 900mm x 1800mm
Control Panel Digital/PLC Based
Frame Construction Skid Mounted, Powder Coated MS/SS
No. of Membranes 4-6 (depending on design)
Net Weight Approx. 650-750 kg
Total Dissolved Solids (TDS) Rejection up to 99%
Output Water Quality Potable/Process Water
Pre-filtration Stage Multimedia/Activated Carbon/Sediment
Inlet Pressure Required 2-3 kg/cm2
Feed Water Temperature 5C - 45C
Cleaning System CIP (Clean In Place) Provided
Membrane Type Polyamide Thin Film Composite

5000 LPH RO Plant Product Specifications

Pump Type High Pressure Multistage Pump
Purity Level up to 99% TDS removal
Material 220-380V
Capacity 5000 LPH
Frequency 50 Hz
Flow Rate 5000 LPH
Product Type Electricity
Feature Mild Steel
Usage & Applications Industrial, Commercial, Food & Beverage, Hospitals, Hotels
Water in conductivity <2000 S/cm
Water Source RO Plant
Filter Type Multi-stage (Pre, Carbon, Micron, RO Membrane)
Drive Type Electric Motor
Water Out Conductivity <10 S/cm
Automatic Grade Borewell Water
Noise Level <70 dB
Installation Type Floor Mounted
Power Source Electric
Recycle Rate 90-95% (adjustable)
Volume 5000 liters/hour
Ph Level 6.5 - 8.0 (adjustable output)
Power Consumption 5-8 kW approx.
Technology Reverse Osmosis (RO)
Voltage 380-415V, 50Hz
Efficiency (%) >98%

Dimensions (LxWxH) Approx. 2600mm x 900mm x 1800mm
Control Panel Digital/PLC Based
Frame Construction Skid Mounted, Powder Coated MS/SS
No. of Membranes 4-6 (depending on design)
Net Weight Approx. 650-750 kg
Total Dissolved Solids (TDS) Rejection up to 99%
Output Water Quality Potable/Process Water
Pre-filtration Stage Multimedia/Activated Carbon/Sediment
Inlet Pressure Required 2-3 kg/cm2
Feed Water Temperature 5C - 45C
Cleaning System CIP (Clean In Place) Provided
Membrane Type Polyamide Thin Film Composite

5000 LPH RO Plant Trade Information

Supply Ability 1 Piece Per Day
Delivery Time 1 Days

Product Description

Supported ourselves with proficient amenities, we are providing a supreme range of 5000 LPH RO Plant. It is ideal for small to medium industries which includes food, textile, chemical etc. Apart from this, we ensure this plant un an easy mode of payment solutions. 5000 LPH RO Plant is to purify or desalinate contaminated water by forcing water through a membrane. It is equipped in a such a way to fulfil the needs at a smaller level.

Advanced Water Purification Technology

Utilizing reverse osmosis technology with polyamide thin film composite membranes, this plant ensures a TDS rejection of up to 99%. Its multi-stage filtration, including multimedia, activated carbon, and sediment filters, delivers high purity output suitable for sensitive industrial and commercial applications.

Robust, User-Friendly Construction

Built on a skid-mounted, powder-coated mild steel or stainless steel frame, the RO Plant is designed for durability and easy installation. The integrated CIP (Clean-In-Place) system, digital or PLC-based control panel, and floor-mounted design enhance operational convenience and longevity.

Versatile Applications Across Industries

With a flow rate of 5000 liters per hour and adjustable output quality, the RO Plant serves a wide range of sectors, including food and beverage, hospitals, hotels, and general industrial processes. Its consistent performance ensures high-quality water wherever required.

FAQ's of 5000 LPH RO Plant:

Q: How does the 5000 LPH RO Plant achieve high water purity?

A: The plant employs a multi-stage filtration system with polyamide thin film composite membranes to remove up to 99% of dissolved solids. Pre-filtration through multimedia, activated carbon, and sediment filters eliminates larger contaminants, ensuring optimal RO membrane performance and high-purity output.

Q: What are the installation requirements for this RO Plant?

A: Installation requires a floor-mounted setup with access to an electric power supply (220-380V, 50Hz), suitable water inlet pressures (2-3 kg/cm2), and enough space for its approximate dimensions (2600mm x 900mm x 1800mm). The robust skid-mounted frame simplifies installation in diverse industrial environments.

Q: When should the Clean-In-Place (CIP) system be used?

A: The CIP system should be employed periodically or when the system's performance indicates fouling, such as a decrease in output rate or purity. Routine cleaning helps maintain membrane efficiency and prolongs the operational lifespan of the plant.

Q: Where can the 5000 LPH RO Plant be utilized effectively?

A: This RO Plant is ideal for industrial and commercial settings, such as manufacturing units, food and beverage processing, hospitals, hotels, and other facilities requiring large volumes of potable or process water. It can be adapted to various water sources, including borewell water.

Q: What is the typical process flow within the RO Plant?

A: Feed water passes through multi-layer pre-filtration (multimedia, activated carbon, and sediment), undergoes high-pressure pumping, is filtered by RO membranes, and then processed water is collected while rejected salts and impurities are flushed, achieving high recycle rates of 90-95%.

Q: How does the digital/PLC-based control panel benefit users?

A: The advanced control panel simplifies system monitoring and operation, enabling precise adjustments to parameters such as output flow, pH, and conductivity. It ensures user-friendly operation, supports troubleshooting, and provides system status updates in real time.

Q: What are the benefits of having a high recycling rate in this RO Plant?

A: A recycle rate of 90-95% reduces water wastage and operational costs, making the RO plant environmentally friendly and economically efficient for large-scale water treatment requirements.
